8906 Nidec | 1 hp 1075 RPM 3-Speed 115V; 5.6" Blower Motor

Product Description

8906 Nidec | 1 hp 1075 RPM 3-Speed 115V; 5.6" Blower Motor

This 1 horsepower blower motor is designed for HVAC applications requiring reliable, continuous-duty performance. It replaces compatible motors with similar specifications and is ideal for systems needing a reversible rotation and multiple speed settings.

Key Specifications

• Horsepower: 1 hp
• RPM: 1075
• Voltage: 115V
• Amperage: 12.1 amps
• Enclosure: Open Air Over
• Frame / Diameter: 5.6" diameter, motor case length 6.062"
• Shaft Dimensions: 0.5" diameter x 5.0" length
• Rotation: Reversible
• Bearings: Sleeve Bearings

Product Features & Fitment

This permanent split capacitor motor includes automatic overload protection and is rated for continuous duty with Class B insulation, suitable for ambient temperatures up to 40°C. It requires a 20 MFD 370V capacitor for operation and features 24" leads for easy wiring. The motor is designed for band and hub mounting, facilitating straightforward installation in compatible blower assemblies.

Warranty

1 Year Manufacturer Warranty
